THIS IS A BASIC GUIDE WHEN DOING SERVICING IN HOUSE WE DO THIS JUST TO KEEP UP WITH BASIC MAINTENANCE AND SPOT ANY PARTS THAT MAY CAUSE MAJOR DAMAGE IF NOT REPLACED

-- RUN STEAM CLEANER WITH PRESSURE MAKE SURE THAT BURNER AND PUMP ARE WORKING GOOD ALSO PRESSURE LEVELS SHOULD NOT EXCEED 2000 KPI DO A PRE CHECK BEFORE STARTING SERVICE TO MAKE SURE STEAM CLEANER IS WORKING GOOD BEFORE MAINTENANCE

--THESE ARE BASIC STEPS FOR STARTING SERVICE SEE BELOW

--FIRST POWER AND WATER OFF

--DRAIN DIESEL FROM FUEL TANK

--REPLACE DIESEL FUEL FILTER ONLY USE HD296 AS THIS IS WHAT WAS SUPPLIED WITH MACHINE WHEN PURCHASED

--REPLACE OIL IN PUMP ONLY USE MANUFACTURES SPECIFIED OIL SAE20/30  TO DO THIS REMOVE BUNG FROM BACK OF PUMP THERE ALSO SHOULD BE A BREATHER SCREW LOCATED ON TOP OF PUMP REMOVE AND DRAIN ALL OIL ONCE DRAINED REFILL FROM BREATHER MAKE SURE NOT TO OVER FILL THERE IS A GAUGE ON PUMP


--CHECK WATER FLOAT MAKE SURE NOT DAMAGED FROM HEAT

--CHECK HIGH PRESSURE HOSE AND LANCE THE HANDLE ON LANCE SHOULD BE ABLE TO TURN PRESSURE DOWN FREELY IF NOT THEN REMOVE NUT AND INSPECT

--CHECK WATER HOSE AND TAPE FITTINGS ONCE INSPECTION IS OK REPLACE DIESEL AND TURN WATER AND POWER ON BE SURE THAT STEAM CLEANER HAS A FULL TANK OF DIESEL AND THAT WATER PUMP OIL GAUGE IS READING ABOVE HALF WAY MARK ONCE THESE HAVE BEEN CHECKED PULL THE TRIGGER ON LANCE CHECK OIL PUMP GAUGE TO MAKE SURE THAT LEVELS HAVNT DROPED HOT WATER BURNER AND PUMP SHOULD BE WORKING GOOD
